Power consumers (motor, heating, light)
(Snaga potrošači (motor, grijanje, svjetlo))
SIMBOL
OPIS
01.
AC motor, ventilating fan
(AC motor, ventilaciju ventilator)
02.
DC motor, ventilator / fan
(DC motor, ventilator / ventilator)
03.
DC motor, general
04.
Shunt motor, DC
(DC motor sa šantom)
05.
Series motor, DC
06.
DC motor, general, with straight connection point
(DC motor, general, sa pravim priključenja)
07.
DC motor, general, with straight connection point
(DC motor, general, sa pravim priključenja)
08.
DC motor with brushes, general
(DC motor sa četkicama, general)
09.
AC motor, without PE, with straight connection point
(AC motor, bez PE, sa pravim priključenja)
10.
AC motor
11.
AC motor for ventilating fan
(AC motor za ventilaciju ventilatora)
2
SIMBOL
OPIS
12.
Three-phase asynchronous motor, one rotation speed
(Trofazni asinhroni motor, brzina rotacije jedan)
13.
Three-phase asynchronous motor, one rotation speed
(Trofazni asinhroni motor, brzina rotacije jedan)
14.
Actuator motor
(motor pokretač)
15.
Three-phase motor for ventilating fan
(Trofazni motor za ventilaciju ventilator)
16.
AC motor, with two directions of rotation (control valves)
(AC motor, s dva smjera vrtnje (regulacijski ventili))
17.
Stepping motor, general
(Koračni motor, općenito)
18.
Stepping motor, general
(Koračni motor, općenito)
19.
AC motor with thermal cut-out
(AC motor s termalnom izrezu)
20.
AC motor with thermal monitoring
(AC motor s termalnom nadzor)
21.
Three-phase induction motor, star-delta connection
(Trofazni asinkroni motor, zvijezda-trokut)
22.
Three-phase induction motor, star-delta connection
(Trofazni asinkroni motor, zvijezda-trokut)
4
SIMBOL
OPIS
33.
Three-phase asynchronous motor with thermal monitoring,
two separate windings, change-pole, three rotation speeds
(Trofazni asinkroni motor s termalnom nadzor, dva odvojena
namota, promjena polova, tri brzine rotacije)
34.
Fluorescent lamp without PE
(Fluorescentna žarulja bez PE)
35.
Fluorescent lamp with PE
(Fluorescentna žarulja s PE)
36.
Enclosure light with female receptacle
(Kućište svjetla sa ženskim posude)
37.
Enclosure light with female receptacle
(Kućište svjetla sa ženskim posude)
38.
Heating element
(Grijač)
39.
Heating element with PE
(Grijanje element PE)
Valve, brake and coupling
(Ventila, kočnice i spojke)
40.
Solenoid valve, general
(Elektromagnetski ventil, općenito)
41.
Solenoid valve, general (stretched)
(Elektromagnetski ventil, općenito (rastegnut))
5
SIMBOL
OPIS
42.
Solenoid valve, with plug-in connection (stretched)
(Elektromagnetski ventil, uz plug-in priključak (rastegnut))
43.
Solenoid valve, coil, with plug-in connection
(Elektromagnetski ventil, zavojnica, uz plug-in priključak)
44.
Solenoid valve, with PE, plug-in connection
(Elektromagnetski ventil, sa PE, plug-in priključak)
45.
Solenoid valve, 2 coils
(Elektromagnetski ventil, 2 zavojnice)
46.
Solenoid valve, 2 coils, with plug-in connection
(Elektromagnetski ventil, 2 zavojnice, uz dodatak vezi)
47.
Solenoid valve, double-acting valve (Part 1)
(Elektromagnetski ventil, dvostruko djelujući ventil (Dio 1))
48.
Solenoid valve, double-acting valve (Part 2)
(Elektromagnetski ventil, dvostruko djelujući ventil (2. dio))
49.
Solenoid valve, double-acting valve (Part 3)
Elektromagnetski ventil, dvostruko djelujući ventil (3. dio)
50.
Solenoid valve, double-acting valve (Part 4)
(Elektromagnetski ventil, dvostruko djelujući ventil (4. dio))
51.
Solenoid brake
(Solenoid za kočnice)
52.
Solenoid brake, three-wire
(Solenoid kočnice, tri žice)
53.
Magnetic clutch
(Magnetska spojke)
7
SIMBOL
OPIS
65.
Current transformer (path 1)
(Trenutno transformator (staza 1),(staza 2),(staza3))
66.
3-phase line reactor for NC devices
(3-fazni vod reaktor za NC uređaja)
67.
Inductor with magnetic core, three-phase
(Zavojnica s magnetskom jezgrom, trofazne)
68.
Resistor, general
(Otpornik, općenito)
69.
Resistor, inherent, non-linear
(Otpornik, svojstvena, nelinearna)
70.
RC network
(RC mreže)
71.
Resistor, carbon pile
(Otpornik, ugljik gomila)
72.
Photoresistor
(fotootpornik)
73.
Resistor with movable contact
(Otpornik s pokretnim kontakt)
74.
Resistor with movable contact and "Off" position
(Otpornik s pokretnim kontakt i položaju "OFF")
75.
Resistor, variable
(Promjenjivi otpornik)
76.
Resistor, adjustable
(Otpornik, podesivi)
